6" Trim saw
SKU: 22-319
Our American-made 6″ trim saw is the perfect saw for trimming-out cabochon preforms in rocks, minerals and glass, or to cleanly trim facet material. This saw includes TWO different types of 6″ saw blades to best-suit your cutting material; one economy silver notched diamond saw blade and one premium, long-lasting red sintered diamond saw blade. Saws are available with or without the saw vise accessory.
The Hi-Tech Diamond 6" trim saw is manufactured with a 5/8" arbor and will accept any 6" saw blade that has a 5/8" arbor. The saw table has a large work area, measuring 15-1/2" L X 9" W. The housing is made of unbreakable, cross-linked polyethylene that makes it rustproof and easy to clean. Installed in each saw is a 1/4 hp, heavy-duty, direct drive permanent magnet motor with sealed ball bearings. The motor is variable speed and can deliver speeds from 800 to 3,400 rpm. The coolant reservoir is built right into the base of the machine and can hold up to 16 ounces of water. The removable saw table that covers the reservoir makes cleanup easy. The splash guard that comes with the machine keeps water off you and on your piece, making it easier for you to work.
This Hi-Tech Diamond 6" trim saw machine comes with TWO different types of 6" saw blades to best-suit your cutting material. The silver notched diamond saw blade is designed for cutting rocks and minerals such as turquoise, aqua, garnet, corundum, emerald and ruby, while the red sintered diamond saw blade is designed for cutting pieces of glass, topaz, quartz and fine agates.
Electricity supply
Make sure you choose the right power supply for your machine. The 220 volt models are available only for overseas customers that require 220V - 240V power supply. All 220 volt models are manufactured with this CE rated, Type F plug (see below):
International customers
We are not responsible for any import duties or customs charges. Any such fees incurred to receive your package are not covered by us. Please consult your country's customs policy for more information. For Europe sales, please contact Inland Craft Europe at inlandcraft@t-online.de. For Australia sales, please visit Aussie Sapphire at www.aussiesapphire.com.au.
6" trim saw includes
- 6" x .012" x .015" silver notched diamond saw blade
- 6" x .015" x .023" red sintered diamond saw blade
- Black spray shield
- Allen wrench
- Hi-Tech Diamond waterproof apron
- Complete written and visual instruction manual
- One-year manufacturer warranty
6" trim saw specifications
- Machine dimensions: 17" L X 17" W X 11" H
- Machine weight: 15 lbs
- Saw housing construction: rustproof, cross-linked polyethylene
- Motor type: 1/4 hp variable speed direct drive motor with speeds ranging between 800 rpm - 3,400 rpm
- Motor voltage: 115V or 220V
- Saw blade height: 1-3/4"
- Saw blade depth: 5-1/4"
- Country of origin: U.S.A.
- Shipped from: U.S.A.
Optional accessories
The 6" trim saw is available with or without the saw vise. This useful accessory is a precision tool that secures and holds your valuable material while you cut. All you have to do is manually advance the carriage to feed your material into the saw blade. This is a great tool if you don't want your hands near the blade or if you require very precise cuts. Installation is fast and easy. Make sure to check out our other useful saw accessory, the saw fence!
Extended warranty programYou’re about to make a smart investment by purchasing a Hi-Tech Diamond trim saw machine so protect it with our extended warranty program. Our extended warranties extend the one-year manufacturer warranty that is included with the trim saw. Choose from either a one- or two-year warranty extension. We recommend purchasing this extended warranty at the same time you purchase your Hi-Tech Diamond machine.
Customer Reviews
Tried three blades- the saw seems weak and stalls repeatedly - as I don’t have anything to compare it to- I can only speak to my experience- the price seems excessive for such a crappy motor
Wish I had bought this sooner than I did, I have already gotten a lot of use out of it. It cuts super fast and smooth with no kickback, but would like to have seen a drain plug on the water reservoir.
I recently embarked on a mission to create jewelry from agates collected by a lost loved one. I want to make beautiful reminders for family and friends. I have a decent shop and am comfortable with tools but a complete lapidary newb. This saw is great.
Best advice I have is watch a few youtube videos of folks like using this, follow their lead, it works as shown in many decent hobbist vids in my experience.
Here's a couple I like:
https://youtube.com/@agatedad?feature=shared
https://youtube.com/@agateariel?feature=shared
It's great lightweight and I can use it inside without worrying everything might get to wet.
Saws like your slicing butter!
